19" 0,5U patch panell, 24 porta fyrir mola. DN-91422

13.100 kr.

Vöruflokkar: , Merki: , Framleiðandi:
Láttu aðra vita

Lýsing

Patch panelar fyrir Cat6 mola. Þessi er aðeins 0,5U á hæð þannig að helmingi meira af tengjum kemst fyrir. Passa í 19″ rekka.

DIGITUS Modular Patch Panel, shielded

  • Layout Keystone Entry: Double-row
  • Area of application: 483 mm (19″) cabinet
  • Norms: ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C
  • General properties:
  • Suitable for 483 mm (19″) cabinet mounting
  • Suitable for shielded Digitus® Keystone Modules and Couplers
  • Central ground connection
  • Plastic label field
  • Technical properties:
  • Housing material: 1.5 mm SPCC cold rolled stell sheet, powder-coated
  • Material standard: EN 10 130(1991), BS 1449, NFA 36/401, DIN 1623, UNI 5866, UNE 36-086, SIS, JIS G 3141, ASTM, SAE, NFA 36/401
  • Grounding bar material: Galvanized steel
  • Grounding wire: 18 AWG, 40 cm
  • Physical properties:
  • Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
  • Category: CAT 6A
  • Ports: 24
  • Color: black, RAL 9005
