Qualification, commissioning and troubleshooting – intuitive, flexible, fast
High data transmission rates of up to 10Gb/s Ethernet and new Power-over-Ethernet applications up to 90W lead to completely new challenges in the field of structured cabling. NetXpert XG2 offers comprehensive active and passive network testing up to 10Gb/s for qualification, commissioning and troubleshooting on copper and fiber cabling. With the largest touch display in its class, NetXpert XG2 guarantees easy operation and clear presentation of results. At the same time, NetXpert XG2 offers highest reliability of results due to the unique combination of up to four different test methods for the evaluation of a data link.
Flexible, expandable model range – upgradeable from 1 to 10Gb/s
NetXpert XG2 and XG2-PLUS qualify twisted pair cabling from 1 to 10Gb/s. With their unique combination of 4 measurement methods, these devices check whether your cabling can transmit Ethernet up to 10Gb/s without interference.
The NetXpert XG2 is available in the smallest version starting at 1Gb/s and can be upgraded up to 10Gb/s.
The NetXpert XG2-PLUS is fully equipped to also qualify fiber optic cabling up to 10Gb/s.
Advantages NetXpert XG2
| Areas of application |
|
| Special characteristics |
|
| Your benefit |
|
|
SPECIFICATIONS – ALL MODELS |
|
|
Copper Interface |
1 x Cat 6A RJ45, interchangeable |
|
Fiber optic interface |
2 x SFP slot 1 – 10Gb/s (please order SFP modules separatly) |
|
Length Measurement Technology |
Time-Domain Reflectometry (TDR) and capacitance |
|
Cable Testing and ID |
Up to 1000ft (305m) – Split Pair Detection: 3ft (1m) to 1000ft (305m) – Length Measurement: 0 to 1500ft (457m), ± (5%+1ft (30cm)) – Distance to fault: 0 to 656ft (200m) ± (5% + 3ft (1m)) – Supports 8 wiremap remotes (RJ 45) and 24 RJ45 ID only remotes |
|
Power over Ethernet (PoE) |
Test supports IEEE 802.3af PoE (Type 1, max 15.4W), IEEE 802.3at PoE+ (Type 2, 30W) and 802.3bt PoE++ (Type 4, 90W) |
|
Maximum Voltages |
Maximum voltage that can be applied to any 2 connector pins without causing damage to the tester: RJ45: 60VDC or 50VAC |
|
Storage Capacity |
Stores an unlimited number of cable tests per projects with user defined names |
|
Tone Generation |
Tone Frequencies: 730Hz and 1440Hz |
|
Languages |
English, German, French, Spanish, Italian |
|
Battery |
Li-Ion, 7.2 VDC, 6.2A-hr / up to 4 hrs (typical) |
|
External Power Supply |
12VDC |
|
Temperature |
Operating: 14 to 140°F (-10 to 60°C) Storage: -22 to 158°F (-30 to 70°) |
|
Humidity |
10 to 90% non-condensing |
|
Enclosure |
Injection molded plastic |
|
Display |
7˝ Color TFT-LCD capacitive touch display, 1024 x 600 resolution (WSVGA) |
|
Size |
245 x 177 x 73mm (Main unit) 130 x 177 x 55mm (Active Remote) |
|
Weight with Battery |
1.2kg (main unit) 0.6kg (Active Remote) |
Hvaða mælir hentar þínum aðstæðum? |
Skoðaðu samanburð mælanna (PDF) |
Skjölun:
NetXpert XG2 series comparison chart
|
|
 |
 |
|
|
|
Features |
NetXpert XG2 |
NetXpert XG2 |
NetXpert XG2 |
NetXpert XG2 |
|
Active network test on Copper |
 |
|
|
|
|
Passive qualification test on Copper |
|
|
|
|
|
Active network test on Fiber Optic (SM/MM) |
|
|
|
|
|
Passive qualification test on Fiber Optic (SM/MM) |
|
|||
|
Maximum speed: |
10Gbps |
10Gbps |
5Gbps |
1Gbps |
|
Mainframe unit: |
2 |
1 |
1 |
1 |
|
Active remote unit: |
1 |
1 |
1 |
1 |
|
Upgradeable to NetXpert XG2 – 2.5/5G |
|
|||
|
Upgradeable to NetXpert XG2 – 10G |
|
|
||
|
Upgradeable to NetXpert XG2 – PLUS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Compatible with ID remote identifiers |
|
|
|
|
|
Compliant to IEEE 802.3an Standards to support up to 10Gbps |
|
|
|
|
|
Compliant to 802.3af/at/bt to support PoE/+/++ testing |
|
|
|
|
|
Compliant to Wi-Fi 802.11a/b/g/n/ac to support Wi-Fi. |
|
|
|
|
|
Generate graphical PDF reports |
|
|
|
|
