Lýsing
Þetta útvarp er tilbúið fyrir móttöku á LW frá Gufuskálum og Eiðum.
Details
Tecsun PL-310ET is a DSP (Digital Signal Processing) multi-band portable radio. It uses DSP 4734 micro-chips (from Silicon Labs in USA) to digitalize the analog MW / FM / SW broadcasting signal base through modern software technology and radio principles. It greatly improves the radio’s sensitivity, selectivity, S/N ratio and anti-interference. Compared to its predecessor, PL-310, is equipped with Easy Tuning Mode (ETM), Tecsuns own designed tuning method. ETM provides the user the possibility to auto-scan for new radio stations, without replacing stations that are already stored into the radios memory. ETM is an ideal feature for users who listen to radio broadcastings at different locations.
Frequency Range:
FM range selectable:
64 – 108MHz
76 – 108MHz
87 – 108MHz
MW (AM) range selectable:
9kHz steps: 522 – 1620kHz
10kHz steps: 520 – 1710kHz
LW: 153- 513kHz
SW: 2300 – 21950kHz.
Tuning Methods:
Easy Tuning Mode (ETM): auto-scan for new radio stations, without replacing existing stored memories. Newly found stations will be temporarily stored into the ETM memory.
Auto Tuning Storage (ATS) for FM / MW / LW /SW
Jog dial manual Tuning
Direct keypad frequency entry
Basic Features:
Multi-functional Digital Display shows:
Frequency
Signal strength
S/N ratio
Clock & Alarm (12/24 hour format)
Temperature (°C or °F)
Battery consumption
LCD display screen
500 preset memories (100 memories for each MW / FM and LW, 200 memories for SW)
Alarm by radio or “buzz”, and with the automatically alarm stopper within 1 – 90 minutes
Sleep timer (1 – 120 minutes)
FM Mono & Stereo
Light & snooze function – 5 minutes, repeated three times
Keylock function
Volume with 30 sound levels
Back stand
Earphone jack
FM & SW antenna jack
DC 5V mini-USB jack
Built-in charging system to charge Ni-MH rechargeable battery
Power supply: mini-USB 5V/250mA external adaptor (not included) / 3pcs AA size batteries (not included)
Unit size: 135 x 83 x 27 mm (L x H x W)
Original accessories: stereo earphones, protective sleeve, USB cable, and English manual
Specification:
Noise Limit Sensitivity
FM < 3uV
MW < 1mV/m
LM < 10mV/m
SW < 18uV
AM IF bandwidth
1, 2, 3, 4, 6 kHz
