WiFi 5
4 samtíma straumar
115 m² (1,250 ft²) drægni með innbyggða loftnetinu
200+ tengjanleg tæki
Keyrt með PoE
GbE tenging
Versatile wall, ceiling, and pole mounting
(2) RP-SMA connectors for optional external antennas
Weatherproof (outdoor exposed)
Lýsing
Unmatched Versatility
The Ubiquiti Swiss Army Knife Ultra is a compact indoor / outdoor PoE access point that delivers powerful wireless coverage and connectivity to your network. With its versatile mounting options and long-range antenna capabilities, the UK-Ultra is a true Swiss Army Knife of wireless connectivity. Experience exceptional wireless performance with Wi-Fi 5 (2×2 MIMO) technology, capable of supporting up to 200+ connected devices and enjoy smooth streaming, seamless file transfers, and lag-free online gaming.
Effortless Deployment
The UK-Ultra is powered from an existing Ethernet network, eliminating the need for additional power cables. Its compact form factor allows for discreet mounting on wall, ceiling or pole, making it ideal for both indoor and outdoor deployments. You can expand the coverage with two RP-SMA connectors for optional external antennas (sold separately). The additional omnidirectional or directional antennas enable you to tailor the UK-Ultra’s signal strength and direction to optimize coverage for your specific needs.
| Mechanical | |
|---|---|
| Dimensions | 137 x 84 x 34 mm (5.4 x 3.3 x 1.3″) |
| Weight | 173 g (6.1 oz) |
| Enclosure material | UV-stabilized polycarbonate |
| Mount material | Polycarbonate, SGCC steel, plastic |
| Pole mount diameter | 1~2″ on pipe outer diameter |
| Wind survivability | 33.2 N at 200 km/h (7.5 lbf at 125 mph) |
| Weatherproofing | IPX6 |
| Hardware | |
| Networking interface | (1) GbE RJ45 port |
| Management interface | Ethernet |
| Power method | PoE |
| Power supply | UniFi PoE Switch |
| Supported voltage range | 44—57V DC |
| Max. power consumption | 8W |
| Max. TX power 2.4 GHz 5 GHz 6 GHz |
20 dBm 20 dBm – |
| MIMO 2.4 GHz 5 GHz 6 GHz |
2 x 2 2 x 2 – |
| Throughput rate 2.4 GHz 5 GHz 6 GHz |
300 Mbps 866.7 Mbps – |
| Antenna gain 2.4 GHz 5 GHz 6 GHz |
4.7 dBi 6.1 dBi – |
| Antenna | (1) Internal antenna (2) RP-SMA connectors for optional external antennas |
| LEDs | (1) Power: white/blue (4) Mesh signal: blue |
| Button | Factory reset |
| Mounting | Wall, ceiling, pole (Included) |
| Ambient operating temperature | -40 to 60° C (-40 to 140° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
| WiFi standards | 802.11a/b/g/n/ac |
| Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| BSSID | 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest traffic isolation | Supported |
| Concurrent clients | 200+ |
| Supported Data Rates | |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n (WiFi 4) | 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) |
| 802.11ac (WiFi 5) | 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80) |
| Application Requirements | |
| UniFi Network | Web: Version 8.0.7 and later iOS™: Version 10.11.1 and later Android™: Version 10.10.1 and later |
