Lýsing
- Dimensions 212.8 x 127.6 x 30 mm (8.3 x 5 x 0.5 „)
- UniFi Application Suite
- Network ✓
- Protect ✓
- Access ✓
- Talk ✓
- Connect ✓
- Managed UniFi Devices 50+
- Managed Cameras (15) HD (8) 2K (5) 4K
- Simultaneous Users Connected 500+
- Default WAN Ports (1) 10G SFP+ (1) 10 GbE RJ45
- LAN Ports (1) 10G SFP+ (4) 2.5 GbE RJ45
- IDS/IPS Throughput 5 Gbps
- Form Factor Compact desktop
- Stateful Firewall ✓
- Application-Aware Layer 7 Firewall ✓
- DPI & Traffic Identification ✓
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) ✓
- Content Filtering ✓
- Intrusion Prevention (IPS/IDS) ✓
- Ad Blocking ✓
- IDS/IPS Signatures 55,000+ with CyberSecure
- VLAN/Subnet-based Traffic Segmentation ✓
- License-Free SD-WAN ✓
- Site-to-Site VPN
- Site Magic ✓
- IPsec ✓
- OpenVPN ✓
- VPN Server
- Identity Endpoint One-Click VPN ✓
- Teleport Zero-Configuration VPN ✓
- WireGuard ✓
- OpenVPN ✓
- L2TP ✓
- VPN Client
- OpenVPN ✓
- WireGuard ✓
- Multi-WAN Load Balancing ✓
- Dynamic Routing
- OSPF ✓
- Advanced QoS ✓
- Multicast DNS (mDNS) ✓
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) ✓
- Integrated RADIUS Server ✓
- RADIUS over TLS (RadSec) ✓
- Additional Internet Failover with UniFi LTE Backup ✓
- Internet Quality and Outage Reporting ✓
- MAC Address Table Size 4,000
- NVR Storage Selectable NVMe SSD up to 2 TB
- PoE Budget 30W
- Max. PoE Wattage per Port by PSE
- PoE+ 30W
- Voltage Range PoE Mode 50-57V
- Max. Power Consumption 29.4W (Excluding PoE output)
- Power Method DC jack (54V DC/1.1A)
- Power Supply 54V DC/1.1A (adapter included)
- Supported Voltage Range 100-240V AC
- Processor Quad-core ARM® Cortex®-A73 at 2.2 GHz
- System Memory 3 GB
- Weight Without SSD: 675 g (1.5 lb) With SSD: 734 g (1.6 lb)
- Enclosure Material Polycarbonate
- LCM Display 0.96″ status display
- Management Ethernet Bluetooth
- LEDs
- Ethernet ✓
- SFP+ ✓
- ESD/EMP Protection Air: ± 8kV, contact: ± 4kV
- Ambient Operating Temperature 0 to 40° C (32 to 104° F)
- Ambient Operating Humidity 5 to 95% noncondensing
- Certifications CE, FCC, IC
- Button (1) Factory-reset
