Dimensions Ø110 x 184.1 mm (Ø4.3 x 7.3″)
- UniFi Application Suite
- Network ✓
- Protect ✓
- Access ✓
- Talk ✓
- Connect ✓
- Managed UniFi Devices 30+
- Managed Cameras (5) HD (2) 2K (1) 4K
- Simultaneous Users Connected 300+
- Default WAN Ports (1) 10G SFP+ (1) 2.5 GbE RJ45
- LAN Ports (3) 2.5 GbE RJ45 including (1) PoE
- IDS/IPS Throughput 2.3 Gbps
- Form Factor Compact desktop
- Stateful Firewall ✓
- Application-Aware Layer 7 Firewall ✓
- DPI & Traffic Identification ✓
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) ✓
- Content Filtering ✓
- Intrusion Prevention (IPS/IDS) ✓
- Ad Blocking ✓
- IDS/IPS Signatures 20,000+ with CyberSecure
- VLAN/Subnet-based Traffic Segmentation ✓
- License-Free SD-WAN ✓
- Site-to-Site VPN
- Site Magic ✓
- IPsec ✓
- OpenVPN ✓
- VPN Server
- Identity Endpoint One-Click VPN ✓
- Teleport Zero-Configuration VPN ✓
- WireGuard ✓
- OpenVPN ✓
- L2TP ✓
- VPN Client
- OpenVPN ✓
- WireGuard ✓
- Multi-WAN Load Balancing ✓
- Dynamic Routing OSPF ✓
- Advanced QoS ✓
- Multicast DNS (mDNS) ✓
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) ✓
- Integrated RADIUS Server ✓
- RADIUS over TLS (RadSec) ✓
- Additional Internet Failover with UniFi LTE Backup ✓
- Internet Quality and Outage Reporting ✓
- MAC Address Table Size 2,000
- Policy-based WAN and VPN Routing ✓
- Customizable DHCP Server ✓
- IPv6 ISP Support ✓
- IGMP Proxy ✓
WiFi Standard 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
Throughput
- 6 GHz 5.7 Gbps
- 5 GHz 4.3 Gbps
- 2.4 GHz 688 Mbps
MIMO
- 6 GHz 2 x 2 (DL/UL MU-MIMO)
- 5 GHz 2 x 2 (DL/UL MU-MIMO)
- 2.4 GHz 2 x 2 (DL/UL MU-MIMO)
Antenna Gain
- 6 GHz 6 dBi
- 5 GHz 7 dBi
- 2.4 GHz 5 dBi
Wireless Security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
Max. BSSIDs 4 per Radio
Supported Data Rates
- 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b 1, 2, 5.5, 11 Mbps
- 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n 6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)
- 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
- 802.11ax (WiFi 6/6E) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
- 802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240/320)
- NVR Storage Pre-installed 64GB microSD for NVR
- Expansion Slot MicroSD Card
- PoE Budget 15.4W
- Max. PoE Wattage per Port by PSE
- PoE 15.4W
- Voltage Range PoE Mode 44-57V
- Max. Power Consumption 26W (Excluding PoE output)
- Power Method Universal AC input, 100-240VAC, 1.5A Max, 50/60 Hz
- Power Supply AC/DC, Internal, 50W
- Max. TX Power
- 6 GHz 24 dBm
- 5 GHz 26 dBm
- 2.4 GHz 23 dBm
- Supported Voltage Range 100-240V AC
- Processor Quad-core ARM® Cortex®-A53 at 1.5 GHz
- System Memory 3 GB
- Weight 1.1 kg (2.4 lb)
- Enclosure Material Polycarbonate
- LCM Display 0.96″ status display
- Management Ethernet Bluetooth
- LEDs System ✓
- ESD/EMP Protection Air: ± 8kV, contact: ± 4kV
- Ambient Operating Temperature -10 to 40° C (14 to 104° F)
- Ambient Operating Humidity 5 to 95% noncondensing
- Certifications CE, FCC, IC
- Button (1) Factory-reset
- VLAN 802.1Q
- Guest Traffic Isolation ✓
- Application Requirements UniFi Network Version 9.0.108 and later
