Unparalleled Network Performance
The Ubiquiti Dream Machine Pro Max is a high-performance network gateway designed for managing large and complex networks. It goes beyond the capabilities of the standard Dream Machine Pro, offering significant upgrades in processing power, memory, routing performance, and security features. This all-in-one solution simplifies network management while delivering exceptional performance and scalability.
Equipped with a powerful multi-core processor and 10 Gbps SFP+ ports, the Dream Machine Pro Max delivers exceptional routing speeds of up to 5 Gbps with full IDS/IPS enabled. This ensures smooth and seamless network traffic management even under heavy loads. The Dream Machine Pro Max boasts advanced switching capabilities with its built-in 8 Gigabit LAN ports and 2 SFP+ ports. This robust switching capacity allows you to connect multiple devices and experience lag-free network performance for various applications.
The Dream Machine Pro Max integrates advanced security features like Integrated Threat Detection/Prevention System (IDS/IPS) and Deep Packet Inspection (DPI). These features help identify and block malicious traffic, protecting your network from cyber threats and unwanted intrusions.
Network Recording with Built-in NVR
The Dream Machine Pro Max features a redundant Network Video Recorder (NVR) functionality with hot-swappable SSD bays. This allows you to record video footage from security cameras and access recordings directly through the UniFi Protect application, ensuring reliable video storage and playback. The integration of network security and video recording allows you to monitor both network activity and video surveillance feeds from a single platform, enhancing overall security management and situational awareness. The Dream Machine Pro Max can support a large number of Ubiquiti UniFi Protect cameras, making it suitable for comprehensive video surveillance solutions in various environments.
Centralized Management
The Dream Machine Pro Max runs on Ubiquiti’s user-friendly UniFi OS, offering a unified platform to manage your entire network. This intuitive interface allows you to easily configure network settings, monitor network health, and access advanced features, all from a single dashboard. The Dream Machine Pro Max integrates seamlessly with other Ubiquiti UniFi devices such as access points, switches, and security cameras. This allows for centralized management and configuration, simplifying network administration and maintenance.
The Dream Machine Pro Max boasts an impressive capacity, supporting up to 200+ UniFi devices and 2,000+ client connections. This makes it ideal for managing large-scale network deployments, including corporate offices, multi-tenant buildings, and educational institutions. The Ubiquiti Dream Machine Pro Max is a powerful and versatile solution for managing large and complex networks. With its exceptional processing power, advanced features and centralized management capabilities, it delivers unparalleled performance, scalability, and ease of use.
Overview
Dimensions 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″)
- UniFi Application Suite
-
- Network Yes
- Protect Yes
- Access Yes
- Talk Yes
- Connect Yes
- Managed UniFi Devices 200+
- Managed Cameras (50) HD (25) 2K (15) 4K
- Simultaneous Users Connected 2,000+
- Default WAN Ports (1) 10G SFP+ (1) 2.5 GbE RJ45
- LAN Ports (1) 10G SFP+ (8) GbE RJ45
- IDS/IPS Throughput 5 Gbps
- Form Factor Rack mount (1U)
- Redundancy Shadow Mode (VRRP) Gateway Failover DC Power Backup
Security
- Stateful Firewall Yes
- Application-Aware Layer 7 Firewall Yes
- DPI & Traffic Identification Yes
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) Yes
- Content Filtering Yes
- Intrusion Prevention (IPS/IDS) Yes
- Ad Blocking Yes
- IDS/IPS Signatures 55,000+ with CyberSecure
- VLAN/Subnet-based Traffic Segmentation Yes
VPN & SD-WAN
- License-Free SD-WAN Yes
- Site-to-Site VPN
- Site Magic Yes
- IPsec Yes
- OpenVPN Yes
VPN Server
- Identity Endpoint One-Click VPN Yes
- Teleport Zero-Configuration VPN Yes
- WireGuard Yes
- OpenVPN Yes
- L2TP Yes
VPN Client
- OpenVPN Yes
- WireGuard Yes
Networking
- Multi-WAN Load Balancing Yes
- Shadow Mode (VRRP) High Availability Yes
Dynamic Routing
- OSPF Yes
- BGP Yes
- Advanced QoS Yes
- Multicast DNS (mDNS) Yes
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) Yes
- Integrated RADIUS Server Yes
- RADIUS over TLS (RadSec) Yes
- Additional Internet Failover with UniFi LTE Backup Yes
- Internet Quality and Outage Reporting Yes
- MAC Address Table Size 4,000
- Policy-based WAN and VPN Routing Yes
- Customizable DHCP Server Yes
- IPv6 ISP Support Yes
- IGMP Proxy Yes
Hardware
- NVR Storage (2) 3.5″ NVR HDD bays Built-in 128 GB SSD for Faster Experience
- Max. Power Consumption 60W
- Power Method (1) Universal AC input, 100-240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A
- Power Supply AC/DC, internal, 100W
- Supported Voltage Range 100—240V AC
- Processor Quad-core ARM® Cortex®-A57 at 2.0 GHz
- System Memory 8 GB
- On-board Storage 32 GB eMMC 128 GB SSD (Integrated)
- Weight 4.7 kg (10.4 lb)
- Enclosure Material Aluminium CNC, SGCC steel
- Mount Material SGCC steel
- LCM Display 1.3″ touchscreen
Management
- Ethernet Bluetooth LEDs
- Ethernet Yes
- SFP+ Yes
- RPS Yes
- PSU Yes
- HDD Yes
- ESD/EMP Protection Air: ± 15kV, contact: ± 8kV
- Ambient Operating Temperature -10 to 40° C (14 to 104° F)
- Ambient Operating Humidity 5 to 95% noncondensing
- Certifications CE, FCC, IC
- Button (1) Factory-reset
